1754 SHALLOW WATER F4

The hull of the Shallow Water F4 was designed by Excel Boats to obtain optimal performance from a surface-drive motor such as a Mud Buddy. The F4’s slick bottom glides over skinny water, logs, mud and vegetation with ease and with the least bit of resistance. The tapered chine provides unparalleled turning capabilities.

BOAT LENGTH

17′

BEAM

69″

MAX HP

50 h.p.

TOW LENGTH

20’6″

SIDE DEPTH

20″

1754 SHALLOW WATER F4

The hull of the Shallow Water F4 was designed by Excel Boats to obtain optimal performance from a surface-drive motor such as a Mud Buddy. The F4’s slick bottom glides over skinny water, logs, mud and vegetation with ease and with the least bit of resistance. The tapered chine provides unparalleled turning capabilities.

1754 SHALLOW WATER F4

The hull of the Shallow Water F4 was designed by Excel Boats to obtain optimal performance from a surface-drive motor such as a Mud Buddy. The F4’s slick bottom glides over skinny water, logs, mud and vegetation with ease and with the least bit of resistance. The tapered chine provides unparalleled turning capabilities.

BOAT LENGTH

17′

BEAM

69″

MAX HP

50 h.p.

TOW LENGTH

20’6″

SIDE DEPTH

20″

SEARCH OUR INVENTORY

NOT SEEING
WHAT YOU’RE LOOKING FOR?

Contact Us! We have new inventory coming in all the time. We can also order any Excel Boat you may be looking for. Call Us! Ramsey MN: 763-450-0400 | Chippewa Falls, WI: 715-833-0060.

F4 SHALLOW WATER

The original step deck transom boat.

The hull of the Shallow Water F4 was designed by Excel Boats to obtain optimal performance from a surface-drive motor such as a Mud Buddy. The F4’s slick bottom glides over skinny water, logs, mud, and vegetation with ease and with the least bit of resistance. The tapered chine provides unparalleled turning capabilities. The F4 step-deck allows you to effortlessly climb in-and-out of the boat and serves as a vantage point for your retriever. This innovative step-deck, introduced by Excel’s owner over 18 years ago with the Mud Buddy MR-18 Mallard with hunt deck, started the shallow water boat step-deck revolution and has set the standard for all high-end shallow water duck boats.

STANDARD FEATURES

  • F4 Step Deck
  • .100 Ga 5052 Aluminum
  • 1 – Seat Base
  • Bow Rails
  • Full Flotation
  • Triple Taper Chine Hull
  • Longitudinal Ribs – 6063 Alloy
  • Recessed Switch Panel W/ Breakers
  • Navigation Lights
  • Slide-In Storage Under Driver’s Seat
  •  Control Panel Interior Light
  • Bilge 800 Gph
  • Fold Down Stand Up Bar
  • High Front Deck With Storage

SPECS

MODELS 1651 1751 1754 1851 1854 1954 1860
Length 16′ 17′ 17′ 18′ 18′ 19′ 18′
Bottom 51″ 51″ 54″ 51″ 54″ 54″ 60″
Beam 68″ 68″ 69″ 68″ 69″ 69″ 75″
Per/Lbs. 4/500 4/560 4/560 4/560 4/560 5/700 5/603
Transom Height 20″ 20″ 20″ 20″ 20″ 20″ 20″
Gunwale Height 25″ 25″ 25″ 25″ 25″ 25″ 25″
Hull Thickness .100 .100 .100 .100 .100 .100 .100
Max HP 50 55 55 60 65 70 70
Max Weight Passengers and Gear 900 1000 1000 1050 1100 1200 1231

POWERED BY

All brands of mud motors work well on our Excel boats. Full feature surface drive motors like the Mud Buddy with electric shift F-N-R, tough outdrives, and reliable power allow the Excel to go places others can only imagine. Whether in the deep timber of Arkansas, the beautiful backwaters of the Everglades, mystical swamps of Louisiana, or the shallow vast grass marshes of the West, this is the boat to own.
